Mooer
Micro Series
Compact Effects Pedals
Ultra Drive
"Limited Edition Model"
Overdrive Pedal
These micro pedals in this series is the latest in a series of nano technology
in the guitar industry. Gone are the 3lb effects pedal days...
Modeled after some famous designs and tones, these pedals reflect
the energy and need of todays musicians while taking up
only a small footprint in your rig.
measuring only 3.6" long x 1.48" wide x 1.33"tall and weighs a mere .33oz
these will fill up your floorboard and give you tons of new sounds.
They are 9 volt powered and can be run together using the three types of
power accessories Mooer has to offer. Up to 5 can run on the standard model
8 on the second and up to 12 on the third power model.
Controls on this Ultra Drive Pedal are as follows
1) Distortion
2) Level
3) Tone
4) Ultra/Extra?Original switch, for three stages of distortion :)
5) Input jack
6) Output Jack
7) Power Adapter Input
Specs:
3 Working Modes: Original/Extra/Ultra
Original: Provide a strong and hard edge distortion sound with low noise level.
Extra: For high gain, and more tube like distortion.
Ultra: For a fatter drive tone, and a wider distortion range
NOTE: these only run on AC power, so a 9V adapter will be needed
we offer these as well specifically for these items from Mooer
Specs:
Effects Modes: 3 (Original/Extra/Ultra)
Input: 1/4” monaural jack (impedance: 470k Ohms)
Output: 1/4” monaural jack (impedance: 10k Ohms)
Power Requirements: AC adapter 9V DC (center minus plug)
Current Draw: 6 mA
